"ZEANON" is an independent brand developed by Qingdao Xindacheng together with European well-known drip line.
Zeanon products cover all aspects of the drip irrigation field, including water-saving irrigation technology & machinery,
engineering design, drip products and drip irrigation pipe machine."ZEANON" is an independent brand developed by Qingdao Xindacheng together with European well-known drip line.
Zeanon products cover all aspects of the drip irrigation field, including water-saving irrigation technology & machinery,
engineering design, drip products and drip irrigation pipe machine.
| Quantity: | |
|---|---|
1. Dripper feeder device: double sets. dripper feeding speed: 3000pcs/min
2. Have dripper buffer device, make sure non-stop machinery even if happen bad quality dripper block on feeder.
3. Extruder: Servo direct drive, save power.
4. Extruder die head & calibrating: Germany technology, thickness adjustable.
5. Configuration: One-button automatic pipe-holding dripper insert device
6. Irrigation pipe accumulator: equipped with the most advanced European parallel accumulator device.
7. Automatic drilling device: 3 units. speed: 3000time/min
8. Configure online automatic imaging analysis and monitoring punching system: monitor the punching status,
realize the error automatic alarm function, and ensure the product punching rate.
9. Line speed: 300m/min, it is the fastest production efficiency in the world.
* dripper space 100mm, speed: 200m/min
* dripper space 200mm, speed: 300m/min
* dripper space 300mm, speed: 300m/min
Zeanon irrigation pipe weights less than 7g/m
Reduce 30% material which will largely save cost
Configured with advanced dripper dripper buffer and insertion unite (Europe technology).
Insert 3000 pieces of dripper per minute.
Advanced dripper,weights only 0.1g/pcs(China exclusive agent)
Qingdao Xindacheng import from Europe, China exclusive agent.
High efficient inner irrigation pipe dripper adopted high efficient injection mold technology.
All produced in Europe, to make sure of the quality.
Double Auto Punching Unit(3 unit)--leading technology in the world
Punching device fixed with online monitor & picture indentify system, store the punching system.
Auto alarm for wrong punching, it is controlled by PLC system,
Tracking and adjust the punching system in time.
Auto winder + Accumulator device
This is an important part of the drip irrigation pipe machine.It is drive by servo motor. Automatically wind the dripper
irrigation pipe. Controlled by PLC system.
Company informations:
Qingdao Xindacheng Plastic Machinery Co., Ltd., a high-tech join-stock enterprise, integrates scientific research development, technology transfer, production and sale. In addition, it is the unit for accomplishing key promotion projects of science and technology result in construction department.
The company mainly engages in research, development, design, manufacture and sales service of new type plastic machinery, is able to provide "Turn-key project" of complete set of production line for many plastic product. It owns powerful technology strength, gathers professional scientific and research talents in top grade macromolecule material national wide, polymer processing, industrial automatization and marketing. Besides, it keeps closely contact with chemical design research institute and universities, so it is familiar with market trend and is able to transfer the latest science and technology achievements in the fastest speed so that to provide whole set of technology such as the most competitive equipment, technology and relevant technology consultation service.
Oriented by human, Xindacheng considers that the innovation and credit is the most important. It will offer first-class product and considerate service to help you in accomplishing great business and cooperate with together to create new era in plastic machinery industry.
Xindacheng always considers that customers' interest is the first important. Over decades, Xindacheng's product spreads all over the country and exported to more than 40 countries and regions such as, U.S. Italy, Canada, South Korea, Japan, Russia, Ukraine, Czech, Turkey, Mexico, Iran, Saudi Arabia, Egypt, Indonesia, Singapore, Taiwan, HK, Malaysia, and wins customers' reputations.
Company board chairman and staff warmly welcome friends from all circles to visit us.
FAQ:
Q: Where is your factory? How can I get there?
Way 1: you take the train to Gaomi station (Weifang City), we will pick you up. It's only 30 minutes from our factory to Gaomi station.
Mode 2: take a plane to Liuting International Airport (Qingdao), we will meet you, 40 minutes from the factory to the airport.
Q: how is your factory doing in quality control?
A: the electrical part has cooperated with famous foreign brands such as Yaskawa, Siemens, NSK, Delta, Panasonic, etc. the other part comes from domestic high-quality manufacturers and will be tested before delivery.
Q: is there any overseas service?
A: Yes, we have an experienced service team. Each team member has gone abroad many times and has rich experience in machine installation. But the buyer needs to provide air tickets, food, hotel fees, etc.
Q: how does your company provide after-sales service?
A: all machines purchased from our company are provided with a one-year warranty period (except for human errors). We will supply some spare parts for replacement at the time of delivery. In case of damage to machine parts in the warehouse, we will send you free parts by express as soon as possible.
